Available to control max 65536 parameters when each session is connected to DPU

Maximum 32 sessions at a time

Console itself can process 6144 parameters

Built-in 8 DMX input/output ports (user-defined)

Up to 256 DMX outputs when connecting to DPU

Built-in 2*15.4 inch and 1 *8.9 inch touch screens

Support a DVI interface to extend an external monitor (or touch screen)

15 pieces electric executive handspikes

2 pieces electric A/B handspikes

One whole control handspike

A built-in keyboard

Built-in uninterruptible UPS power supply

2 Ethernet interfaces

6 USB 2.0 interfaces

MIDI input/output

Audio input/output

Motor-drive display panel

2 motor-drive A/B faders

Adjustable buttons backlight

Fingerprint identification

Equipped with more reliable solid hard disk



Support multi-language operation (Simplified &Traditional Chinese, English, Japanese, Korean, French)

Chinese/Korean/ English input methods

Brand-new design, popular and easy-to-understand with photos and description, user-friendly interface

Support multi-machines backup

Support LTP and HTP, and provide a method for fast switch of LTP and HTP

CITP protocol allows a direct preview of videos from media server



Support MIDI / LTC (SMPTE) and inner time code, can be in sync with time code, convenient for copy and spring

Handheld equipment remote control is available, support IOS/Android handset system.

Powerful vivid stage 3D simulation effect, timely simulating live effect and convenient for off-line programming

Strong layout management, multiple operation modes.

Support multi-protocols: Art-net, SACN, etc, support multi-user operation and user’s permission setting.

Support RDM remote fixture management

Support audio player, built-in music player, clear and smooth



Power Supply: AC100-240V, 1.5A, 50/60 Hz

Net Weight: 54kg

Gross Weight: 81kg

Product Dimension: 961mm x 700mm x 235mm/454mm (extended wing)

Package Dimension: 1078mm x 918mm x 420mm

Package: 1pc/flight case



Max Power: 150W

IP: IP20

Working Temperature: -10°C ~40°C
